Bluetooth watch is a kind of watch with Bluetooth function, it is a kind of multi-functional smart communication watch. Through the Bluetooth function of the watch, it can be used after pairing and connecting with the Bluetooth phone; when the phone has a call, the Bluetooth watch will Vibration alert, caller ID display, 24-hour time display. However, for any product to be sold in the market, there will be corresponding certification regulations. For example, wireless electronic products such as Bluetooth watches must apply for TELEC certification to enter the Japanese market.
What is TELEC certification
The "Radio Law" requires the type approval of designated radio equipment (that is, the certification of compliance with technical regulations). Certification is mandatory, and the certification body is a registered certification body recognized by MIC in the scope of designated radio equipment. TELEC (Telecom Engineering Center) is the main registered certification body for conformity certification of radio equipment in Japan.
TELEC (MIC) certified products
1. 2.4G products
2. Bluetooth products
3. wifi products
4. RFID products
Information to be submitted for TELEC certification
1. Technical model specification table
2. Declaration of Quality Management System
3. Quality control confirmation or manufacturer’s ISO9001 certificate
4. Construction protection certificate
5. Rated power declaration
6. Antenna report
7. Test report (including test results, photos of test equipment and inspection report)
8. (Block diagram, schematic diagram, bill of materials, parts layout, IC data sheet, internal and external photos, product description, user manual, operation/technical description, information/accessory description)
9. Label information
10. Power of Attorney / Authorization Letter
Bluetooth product TELEC certification test project
1. Frequency Error Measurement (Frequency Error Measurement)
2. Coupling bandwidth/carrier frequency bandwidth test (Occupied Bandwidth and Spread-spectrum Bandwidth / Factor)
3. Unwanted Emission Intensity Measurement
4. Antenna Power Error Measurement (Antenna Power Error Measurement)
5. Receiver spurious disturbance test (Limitation of Collateral Emission of Receiver Measurement)
6. EIRP antenna power test (Transmission Antenna Gain (EIRP Antenna Power) Measurement)
7. 3dB lobe bandwidth test (Transmission Radiation Angle Width (3dB Beamwidth) Measurement)
8. Duty Cycle Measurement (Duty Cycle Measurement)
9. Retention time test (retention time)
For Bluetooth watch TELEC certification, please contact our company ZRLK. We will provide you with professional and efficient testing and certification services with favorable prices and courteous service. If you have other products that require TELEC certification, please provide us with product pictures and specifications. We will provide the corresponding cycle, quotation and specific plan according to your product. Welcome to inquire!
